PSA5110B is ideal for bonding: This tape is formulated for bonding low surface energy plastics, giving excellent bond strength on polypropylene and polystyrene, and is also suitable for many other substrates. Read the full product description
Buy in Bulk & Save
1 Roll Only: £29.02Excluding Tax: £24.18Price / Metre: £0.73
Save with Bulk Buying OptionsPrices shown below Exclude Tax1 Roll = £24.18 / Roll4 Rolls - £22.99 / Roll = £91.96 (Save: 4.92% - £4.76)8 Rolls - £21.76 / Roll = £174.08 (Save: 10.01% - £19.36)
How many would you like?
Add to your basket »
PSA code: PSA5110B | Product condition: New | Stock status: In stock
Ask us a question about this productGet a bespoke quote for this product
Orders are dispatched within 1 - 2 working days
Open your account today for 5% off your 1st order
Free standard mainland UK shippingon all orders over £30 (excluding VAT)
Free advice to make your products last longer
Our 1.1mm Thick Gel Tape, PSA5110B, is a: 25mm x 1.1mm x 33 Metres foamed black Structural Acrylic Gel tape. This tape is formulated for bonding low surface energy plastics, giving excellent bond strength on polypropylene and polystyrene, and is also suitable for many other substrates.
This gel tape has a total unity of viscoelastic core section and pressure sensitive adhesive surfaces, with an easy release paper liner.
The thickness of tape selected should depend on the following factors
How much tape you need to use depends on a number of factors. These factors include:
To help you understand what is right for you, as a general rule 0.025m2/kg of tape should be used to hold 1kg in a static situation. However, this will vary from application to application.
There is a safety factor built into this equation; but, you should always test the tape in your own application thoroughly.
This foamed acrylic tape will hold substantial loads, but a safety factor is important in: critical structural applications.
This tape has several key features & benefits. These include:
Along with this, this structural acrylic gel tape has:
Our: foamed acrylic tapes, are made of a: viscoelastic acrylic copolymers and monomers which have a filler comprising of glass microspheres.
The tape is extruded and the curing process is by ultra violet (UV) light, this allows very thin foams to be produced from 0.25mm to thicker foams - up to 3mm thick foam tape - using the same process. The foam used in this tape is naturally tacky (sticky) and has good adhesive properties.
Due to the strength of this type of tape it benefits you, as in most cases does not require holes to be drilled, no rivets to head, epoxies to cure, or weld distortion.
Along with this, these tapes eliminates corrosion between dissimilar metals, and compensate for thermal expansion differences, while providing vibration and sound dampening properties.
Our gel tapes are ideal when: an immediate adhesion is required, you need to bond dissimilar materials, seal joints or just bond thin substrates.
The viscoelastic properties allows the adhesive to flow into the microscopic surface of the materials being bonded. The adhesive bond is very strong when there is good 'wet out', enabling maximum adhesive contact under pressure with the substrates to be bonded.
Abrading the surface to be bonded actually improves the strength of the bond. This abrading creates a rough surface for a greater area for the adhesive to key into.
Along with this the elastic characteristics of the foam, give it very good internal cohesive strength to support loads in both: static and dynamic shear. This also gives the foam very good peel adhesion strength, and is soft and very flexible which means it has great conformability.
The foam also has very good elasticity due to the high internal cohesive strength of the foam, and will radius well, (go around curves).
Surface preparation is paramount for achieving the required bond when using this pressure sensitive adhesive. Read our Surface Preparation and Application Guide for more information on how to apply this foam tape.
If you require the Material Safety Data Sheet (MSDS) for this acrylic tape please do not hesitate to contact us, and we will be happy to send it to you.
If you require a Certificate of Conformance, please contact us after ordering (either by phone or email) and we will get this sent out to you with your order.
